224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯来发电用热车机燃料城市发展性好: 优秀的燃料调节平台，独立拥有的STC、ESTC 定级调节平台，层次性制定的活塞杆上边复燃室，压力输送燃料，有力吸雾，复燃有力。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯发电机组用发起机瞬态耐热性出众: 非凡的发起机整体布局定制，匹配康明斯有趣的EFC操作系统，操作高精性好，反应周期快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电量用打火机升工作功率高: 建筑体设汁紧促.外观简约时尚搭建合理性，自动运行稳步。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷形号 QSNT. QSK19. QSK38. QSK50够满足中国有非高架道路第三点环节及美洲Tier2. Tier 3排放物法规标准追求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零备件可获得性好， 打着机运动及维护日常护理便利店，的价格低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

输出範圍 Power Range   224-310KW结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观简约时尚长宽 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净线质量 Dry Weight   940kg

224-310KW康明斯来发电用打着机的性能：体积大概小， 再压缩变高， 除雾器气体高温，非常易启用，运动车载电子电源线的最佳的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打火机技术参数	实用工作功率(kW)Prime Power	预备耗油率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
